About this design
PVC Assistive Mounting System
The PVC Assistive Mounting System is a collection of readily available commercial-off-the-shelf components and 3D printed components that can be assembled into various configurations to provide mounting solutions for assistive technology.
Configurations
LipSync Desk Mount
The LipSync Desk Mount provides a low cost, adjustable system to mount the LipSync Classic to a flat surface like a table or desk.
Small Button Mount
The Small Button Mount is a simple, inexpensive mounting solution to position a small button on a flat surface.
Large Button Mount
Work-in-progress
Components
Camera Quick Clamp
The PAMS Camera Quick Clamp is a 3D printed adapter for attaching an assistive device to a section of 1/2 inch PVC piping. The clamp has a ¼”- 20 UNC camera thread stud that is compatible with various assistive devices and/or camera mount adapters. The clamp can easily be installed, adjusted, and removed by hand.
Super Clamp Adapter
Work-in-progress
Round Tubing Clamp
Work-in-progress
Wheelchair Rail adapter
Work-in-progress
Resources
More information for working with PVC: PVC Resources
License
PVC Accessible Mounting System by Neil Squire is licensed under a Creative Commons Attribution-ShareAlike 4.0 International License.
About Makers Making Change
Makers Making Change is a program of Neil Squire, a Canadian non-profit that uses technology, knowledge, and passion to empower people with disabilities.
Makers Making Change leverages the capacity of community based Makers, Disability Professionals and Volunteers to develop and deliver affordable Open Source Assistive Technologies.
- Website: www.MakersMakingChange.com
- GitHub: makersmakingchange
- Bluesky: @makersmakingchange.bsky.social
- Instagram: @makersmakingchange
- Facebook: makersmakechange
- LinkedIn: Neil Squire Society
- Thingiverse: makersmakingchange
- Printables: MakersMakingChange
Contact Us
For technical questions, to get involved, or to share your experience we encourage you to visit our website or contact us.
Files
CQC.stl
mesh · 3.5 MB · not watertight · not_watertight
CQC_LeverHandle.stl
mesh · 1.2 MB · not watertight · not_watertight
CQC_LatchArm.stl
mesh · 0.6 MB · not watertight · not_watertight
CQC_LongPin.stl
mesh · 0.1 MB · watertight
CQC_SecondaryBody.stl
mesh · 0.9 MB · watertight
CQC_BoltCover.stl
mesh · 0.0 MB · watertight
CQC_ShortPin.stl
mesh · 0.0 MB · watertight
CQC_MainBody.stl
mesh · 0.6 MB · not watertight · not_watertight
